During adolescence, the growth cartilage of the femoral head is extremely active and influenced by growth hormones (increasing the proliferation of cartilage cells). In certain situations, when the mechanical "stress" on the femoral head exceeds the resilience of cartilage growth, a separation can occur between the head and the neck of the femur. The head may "slip" back and down. This situation is called epiphysiolysis of the upper femur and profoundly alters the mechanics of the hip.

It usually occurs between ages of 11 to 15, being more common in boys. It may be bilateral in 60% of cases.

It manifests itself in most cases by pain in the groin often radiating to the knee. There may be a march with the limb in external rotation and painful limitation of internal rotation.

The deformity resulting from slipping of the epiphysis (femoral head) results in angulation and posterior translation deformity that can be measured in degrees (below 30 º, 30 º to 60 º and over 60 º). Up to 30 º the region of femoral neck which protrudes can penetrate into the acetabular cavity and cause significant damage in the cartilage (type cam mechanism).

If the deformity is more pronounced the prominence of the femoral neck does not penetrate on the acetabular cavity and compresses the labrum damaging it (mechanism type pincer) (video1)

Fig 1: Above the anteroposterior radiograph of a 12 year old child with a bilateral epiphysiolysis and the method of measuring the sliding angle of the epiphysis.

he growth cartilage lesion may be acute and the child begins to have abruptly symptoms. Normally in these situations the lesion is unstable with total inability to walk or, can be chronic, with symptoms appearing more slowly. In some chronic cases there may be exacerbation of symptoms (acute on chronic forms).

Possible complications are the deformity and the acetabular cartilage lesion (fig. 2). There may also be changes in arterial nourishment of the head of the femur, related to the actual deformity. If left untreated the epiphysiolysis can lead to the early onset of coxarthrosis (see section "What diseases can your hip have?")

esquerda: lesão grave da cartilagem direita: visão artroscópica de uma lesão da cartilagem acetabular

Figura 2:
on the left: severe cartilage lesion and labrum caused by cam mechanism resulting from an epiphysiolysis with a deformity of 30 ° (open surgery)
on the right: Arthroscopic view of an acetabular cartilage lesion caused by a epiphysiolysis with a deformity of 20 ° (arthroscopic surgery).

The treatment of the femur epiphysiolysis aims to prevent the worsening of deformity, closure the growth cartilage and correct as well as possible the anatomy, avoiding complications.

Fixation of the femoral head using a screw, accepting the deformation that ends up partially reshaping, is the treatment carried out in many medical centers. It may however persist a mechanism of femoroacetabular impingement that determines an adapted march in external rotation and potential progression to osteoarthritis.

In recent years, the growing knowledge on the femoral head arterial nutrition led to the development of more advanced surgical techniques. The surgery of subcapital "reorientation" of the femoral epiphysis (femoral head) is possible; provided that the small nourishment arteries are separated from the femoral neck and preserved. With this technique it is possible to restore the hip anatomy (fig. 4, 5 and 6).

epifisiolise tratada com fixação com uma parafuso

Figura 3:
On the left: Epiphysiolysis treated by fixation with a screw.
On the right: same hip after 4 years, there is little effective remodeling with a pincer deformity resulting from prominent area of the femoral neck (arrow)


epifisiolise superior do fémur crónica bilateral numa criança de 12 anos

Figura 4: Upper femur chronic bilateral epiphysiolysis in a child age 12


Figura 5:
Above: the technique of femoral epiphysis reorientation allows isolation of the supply arteries of the head along with the muscle insertions in the posterior greater trochanter separating them from the femoral neck.
Figura 5:
In the middle: the epiphysis may be separated from the femoral neck. In order to return to its anatomical position the femoral neck should be reduced (dashed line) so that there is no danger of creating tension in the arteries and decreasing the arterial nourishment.
Figura 5:
Below: anatomical replacement of the epiphysis that should be fixed with screws; with the anatomic reduction mobility returns to normal. The direct visual control on the arteries prevents changes in arterial perfusion

o mesmo caso da figura 4 após reorientação da epifise femoral.

Figura 6: the same case of Image 4 after reorientation of femoral epiphysis.

The development of arthroscopy has also contributed to the correction of deformities in the upper femur epiphysiolysis and prevent any cartilage lesions arising from the femoroacetabular impingement mechanism. Arthroscopy is indicated when the deformity is not very pronounced and must always be associated with femoral epiphysis simultaneous fixation with a screw (video 2; fig. 7 and 8)

epifisiolise com um escorregamento pequeno mas com limitação importante da mobilidade da anca

Figura 7: Epiphysiolysis slip with a small but significant limitation of hip mobility. The arrow shows a small prominence of the femoral neck, but enough to cause intra-articular damage (see video 2 - mobility test shows the prominence entering the acetabular cavity and damaging the labrum and cartilage)


epifisiolise após correcção, semelhante à anca contra lateral

Figura 8: the same case in the previous image after correction similar to the contralateral hip

Video 1: Simulating the mobility of the hip

Simulating the normal mobility of the hip with normal morphology, with a slip of 19 ° and a 30 °. The cartilage and the labrum lesion that take place can be irreversible.

Video 2: Arthroscopy in a child with epiphysiolysis

Arthroscopy in a child with epiphysiolysis
